MOUNTING ELEMENTS

Balcony set
TABLE 1.1 Balcony sets
Set: four M5 screws and 7mm square spindle

tab1 1

Balcony set
TABLE 1.2 Balcony sets for shutters
Set: four M5 screws and 7mm square spindle

tab1 2

M5 set
TABLE 2.1 Sets for profile doors
Set: three M5 screws and 8mm square spindle

tab2 1

M5 set
TABLE 2.2 Sets for profile doors with a knob or a handrail
Set: three M5 screws and 8mm square spindle

tab2 2

M6 set
TABLE 2.3 Sets for profile/ anti-burglary doors (35)
Set: three M6 screws and 8mm square spindle

tab2 3

M6 set
TABLE 2.4 Sets for profile/ anti-burglary doors (35) with a knob or a handrail
Set: three M6 screws and 8mm square spindle

tab2 4

M6 set
TABLE 2.5 Set for profile/ anti-burglary doors (52)
Set: three M6 screws with increased strength and 8mm square spindle

tab2 5

M6 set
TABLE 2.6 Set for profile/ anti-burglary doors (52) with a knob or a handrail
Set: three M6 screws with increased strength and 8mm square spindle

tab2 6

TABLE 2.7 HST mounting sets - handle/ handle

tab2 7

TABLE 2.8 HST mounting sets handle/ grip

tab2 8

TABLE 2.9 HST mounting sets handle/ shutter

tab2 9
